Technical specification
Cable tie wall plug (surface) 25 in
Description
Use
- For fixing of Unex trunkings and modular boxes.
- Universal trunking plug for indoor installations.
- Colour: Black.
Installation
- Pre-mounted plug and screw.
- Applicable to the most usual types of wall.
- No need for special tools: Drill bit Ø6 (Part no.25106) and drill bit Ø4 (Part no.25104).
- Assures electrical safety.
- Easy to mount and remove.
- Halogen free.
Product characteristics
- Raw material: U63X
- RoHS Compliant: Conformity(1)
- Silicone contents: Silicon free (< 0,01%)
Characteristics
|
EN 62275:2019
|
|
|---|---|
|
Minimum installation temperature
|
-5ºC.
|
|
Minimum transport and storage temperature
|
-40ºC to +60ºC
|
|
Material
|
Non metallic
|
Characteristics
EN 62275:2019
Minimum installation temperature:
-5ºC.
Minimum transport and storage temperature:
-40ºC to +60ºC
Material:
Non metallic
Compulsory regulations
|
European Directive 2014/35/EU
|
|
|---|---|
|
CE Marking
|
Conformity with standard EN 62275:2019.
|
Compulsory regulations
European Directive 2014/35/EU
CE Marking:
Conformity with standard EN 62275:2019.
Characteristics of U63X raw material
- Base raw material: Polyamide 6
- Halogen contents according to EN 50642: 2018: Halogen free
- Silicone contents: <0,01% (3)
- Phatalate contents according to ASTM D2124-99:2004: <0,01% (3)
- UL flammability tests on plastic materials according to ANSI/UL 94: 1990: degree UL94 HB
Notes
1. See updated information of each part number on www.unex.net
2. Except for new part numbers, which are under process of obtaining quality marks and approvals. See updated information of each part number on www.unex.net
3. Detection limit for the analytical technique applied.
03/05/2024
Our quality management system complies with the requirements of UNE-EN ISO ISO 9001:2015 for the design, production and commercialization of Unex Systems.
